首页 > 产品展示 > 低频变压器
低频变压器
EI系列
型号 | 系列 | 磁芯尺寸（mm） | 功率(VA) | 220V（230V)/50Hz输入 | 负载电压 | 负载电流 | ||
长 | 舌宽 | 厚 | 空载电流 | |||||
ST-EI28-12 | 28 | 8 | 12 | 0.5-1 | 15mA | 15V | 0.05A | |
ST-EI28-16 | 28 | 8 | 16 | 0.7-1 | ||||
ST-EI35-10 | 35 | 9.6 | 10 | 0.2-0.8 | 13mA | 7.5V | 0.25A | |
ST-EI35-12.5 | 35 | 9.6 | 12.5 | 0.25-1 | ||||
ST-EI35-16 | 35 | 9.6 | 16 | 0.4-1.7 | ||||
ST-EI35-20 | 35 | 9.6 | 20 | 0.6-2.5 | ||||
ST-EI41-13 | 41 | 13 | 13 | 0.6-2.3 | 25mA | 12V | 0.42A | |
ST-EI41-16 | 41 | 13 | 16 | 1-3.6 | ||||
ST-EI41-21 | 41 | 13 | 21 | 1.6-5.5 | ||||
ST-EI41-26 | 41 | 13 | 26 | 2.3-7.7 | ||||
ST-EI48-16 | 48 | 16 | 16 | 2--5 | 10mA | 22V | 0.2A | |
ST-EI48-20 | 48 | 16 | 20 | 2.8-7.2 | ||||
ST-EI48-25 | 48 | 16 | 25 | 4.6-11.1 | ||||
ST-EI48-32 | 48 | 16 | 32 | 7--10 | ||||
ST-EI54-18 | 54 | 18 | 18 | 5--12 | 35mA | 18.5V | 0.8A | |
ST-EI54-22.5 | 54 | 18 | 22.5 | 8--17 | ||||
ST-EI54-29 | 54 | 18 | 29 | 11--25 | ||||
ST-EI54-36 | 54 | 18 | 36 | 17-34 | ||||
ST-EI57-19 | 57 | 19 | 19 | 7--16 | 34mA | 24V | 1.25A | |
ST-EI57-24 | 57 | 19 | 24 | 14-21 | ||||
ST-EI57-30 | 57 | 19 | 30 | 16-32 | ||||
ST-EI57-28 | 57 | 19 | 38 | 20-40 | ||||
ST-EI66-22 | 66 | 22 | 22 | 17-35 | 50mA | 29V | 0.8A | |
ST-EI66-28 | 66 | 22 | 28 | 24-45 | ||||
ST-EI66-35 | 66 | 22 | 35 | 36-58 | ||||
ST-EI66-45 | 66 | 22 | 45 | 55-77 | ||||
ST-EI76-25 | 76.2 | 25.4 | 25 | 65-88 | 60mA | 48V | 2A | |
ST-EI76-31.5 | 76.2 | 25.4 | 31.5 | 71-95 | ||||
ST-EI76-40 | 76.2 | 25.4 | 40 | 70-97 | ||||
ST-EI76-50 | 76.2 | 25.4 | 50 | 86-123 | ||||
ST-EI96-40 | 96 | 32 | 40 | 90-130 | 60mA | 50V | 12A | |
ST-EI96-45 | 96 | 32 | 45 | 100-150 | ||||
ST-EI96-50 | 96 | 32 | 50 | 110-160 | ||||
ST-EI105-35 | 105 | 35 | 500-700 | 55mA | 28V | 18A | ||
ST-EI114-38 | 114 | 38 | 700-1000 | 80mA | 34V | 23A | ||
以上为公司常用款式，其他规格暂未列其中。本公司可按客户要求定制各种低频变压器, 欢迎咨询。 |
